SPEC   \   TYPE
TLP-P450
TLP-P610
TLP-P710
TLP-P810
TLP-P910
TLP-P1000
TLP-P1200
TLP-P1600
Diameter of lapping plate(mm) 450φx50t 610φx  55t 700φx  55t 800φ x  55t 910φx  55t 1000φx  55t 1200φx  60t 1600φ x  65t
Max size product(○-□)(mm) 170-90 248-170 280-190 300-210 350-230 400-280 455-300 650-460
Number of work station
4
3
3
3
3
3
3
3
Work ring size(IDxH)(mm) 171 x 50 250 x 75 282 x 75 303 x 75 353 x 75 403 x 80 458 x 80 655 x 80
Pressure cylinder size(mm) 55φ x 200 63φ x 300 63φ x 350 80φ x 350 80φ x 350 100φ x 350 100φ x 350 125φ x  400
Max pressure (1station) 80kg 120kg 120kg 200kg 200kg 310kg 310kg 550kg
Lapping plate RPM 0~100rpm 0~80rpm 0~80rpm 0~65rpm 0~55rpm 0~55rpm 0~40rpm 0~40rpm
Main motor 1.5kw 2.2kw 2.2kw 3.7kw 7.5kw 7.5kw 11kw 11kw
Net weight 550kg 1320kg 1430kg 1820kg 3200kg 3600kg 3950kg 5280kg

***Polishing machine의 경우는 main motor와 work station(작업링 수)이 상기의 수치와 다르므로 별도로 사양을 제출 합니다.
